Chipset Intel B250
CPU SUPPORT Intel® Core™ i7 LGA 1151 Processor
Intel® Core™ i5 LGA 1151 Processor
Intel® Core™ i3 LGA 1151 Processor
Intel® Pentium® LGA 1151 Processor
Intel® Celeron® LGA 1151 Processor
Maximum CPU TDP (Thermal Design Power) : 95Watt
MEMORY Support Dual Channel DDR4 2400/ 2133/ 1866 MHz
2 x DDR4 DIMM Memory Slot
Max. Supports up to 32GB Memory
* DDR4 2400 for 7th Generation Intel® Core™ Processor Family
EXPANSION SLOT 1 x PCI-E x16 3.0 Slot
7 x PCI-E x1 3.0 Slot(Note: PEX1_6/11 slot are not compatible w/ ATX standard, users need extra coonecting kit to install VGA card for crypto mining.)
STORAGE 6 x SATA3 Connector
USB 4 x USB 3.0 Port
1 x USB 3.0 Header
2 x USB 2.0 Port
2 x USB 2.0 Port(only 5V power, up to 1.5A)
2 x USB 2.0 Header
LAN Realtek RTL8111H - 10/100/1000 Controller
Support Super LAN Surge Protection
INTEGRATED VIDEO By CPU model
Supports DX12
Supports HDCP
CODEC Realtek ALC887 8-Channel HD Audio
Support HD Audio
REAR I/O 1 x PS/2 Mouse
1 x PS/2 Keyboard
4 x USB 3.0 Port
2 x USB 2.0 Port
2 x USB 2.0 Port(only 5V power, up to 1.5A)
1 x DVI-D Connector, resolution up to 1920 x 1200 @60Hz
1 x RJ-45 Port
3 x Audio Connector
INTERNAL I/O 1 x USB 3.0 Header
2 x USB 2.0 Header
6 x SATA3 6Gb/s Connector
1 x SATA Power Connector(for rear USB power enhancement)
1 x Front Audio Header
1 x Front Panel Header
1 x CPU Fan Header
2 x System Fan Header
1 x Serial Header
2 x PCI-E 12V 4Pin Connector(Must be installed when using for bitcoin mining.)
H/W MONITORING CPU / System Temperature Monitoring
CPU / System Fan Monitoring
Smart / Manual CPU Fan Control
System Voltage Monitoring
DIMENSION ATX Form Factor Dimension: 29.5cm x 21cm ( W x L )
OS SUPPORT Support Windows 10(x64) for Intel 7th Generation Processor
?Support Windows 7 / 8.1(x64) / 10(x64) for Intel 6th Generation Processor
BUNDLE SOFTWARE BullGuard
Smart Speed LAN(Windows 7/ 8.1 only)
Intel Rapid Storage Technology
ACCESSORIES 2 x SATA Cable
1 x I/O Shield
1 x DVD Driver
1 x User Manual
DB9 serial port GEMBIRD, CCDB9RECEPTACLE motherboard to serial port
IDC 10pin internal flat cable for connection to motherboard serial port
DB9M connector on the metal bracket
The Vibe Fixer is a special mounting frame that decouples hard disk and PC case. Fixing the hard disk between strong rubber tapes prevents undesired noise caused by vibration.
Thermal compund (grease) for heatsinks
Helps the heat dissipation from a CPU, chipset or processor to a heatsink
Excellent thermal impedance
Perfect stability - will not separate, run, migrate, or bleed
Non capacitive or electrically conductive
Specifications
Weight: 1.5 g
Color: grey
Thermal conductivity: > 4.5 W / mK
Thermal Impedance <0.205 C-in2 / W
Density: > 2.5
Evaporation: <0.001 %
Volatility: <0.005 %
The dielectric constant: > 5.1
Dissipation Factor: <0.005
Viscosity: 76 CPS
Thixotropic index: 310 ± 10 C
Operating Temperature: -50 240 C
Composites: 50% silicone compounds
Compounds: 30% of carbon
The compounds of metal oxides: 20%
